Overhead power line transmission conductor stringing block china

Overhead power line transmission conductor stringing block china

Large Diameter Stringing Pulleys for conductor installation are suitable for s​tringing conductor max up to ACSR 500.​

​About E-Grid

​Ningbo Eastern Grid Power (E-Grid) is China leader in designing, manufacturing and supplying hydraulic brake tensioners for stringing operations, ideal to allow operations to be carried out with the highest accuracy, speed and safety.

Description

The pulleys are suitable for stringing conductor max up to ACSR500.
The pulley wheels are made of aluminium alloy / MC nylon mounted on ball bearings; the groove is lined by a neoprene ring or by wear-proof interchangeable nylon or aluminium wheels. The frame is made of galvanized steel. The pulleys can be supplied with three types of connections: fixed(B), swivel-type(C) or with a hook supplied with safety lock(D). Grounding device or complete conductive sheaves can be supplied on demand.

Order numberModelNumber of sheaveRated load(kN)Weight (kg)Features
10121SHD66012030Rubber Aluminous sheave
10122SHS660340106Middle :cast steel sheave,conductor : cementation aluminous sheave
10123SHW660560150
10124SHDN66012024MC nylon sheave
10125SHSLN66034092Middle :MC nylon sheave conductor,conductor : cementation aluminous wheel
10126SHWLN660560120
10127SHSQN66034076MC nylon sheave
10128SHWQN660560110
10129SHQZ660780268Middle :cast steel sheaveconductor : cementation aluminous wheel
10130SHQ660A775190Middle :cast steel sheaveconductor : MC nylon wheel

Note

Blockdimension (outside diameter × root diameter × sheave width) Φ660×Φ560×100. But wecan supply Block dimensionΦ660×Φ560×90 by customers’ requirement.

Quality Control

We have the complete production equipments and professional production team to manage the whole process from production to packing shipment. All products will 100% test before delivery to ensure the quality.

Remarks

We can supply all kinds of stringing equipment according to customers’ requirements.

Shipment

1. The machines will be shipped in container.
2. We will ship the products within one month normally after receiving the payment.
3. Stock is available for standard product.

Payment

​1. We accept T/T and L/C.
2. Please send swift copy of T/T if you arrange payment by T/T.
3. Please send us the L/C draft to us before issue L/C.

Why choose us

1. High quality and competitive price.
2. Leading and biggest manufacture for stringing equipment in China.
3. 25 years of production experience and more than 1000 customers in the country and abroad market. The machines have been sold to more than 20 countries.
4. Big stock condition for fast shipment.
5. Detailed pre-sales service and fast active after-sales service. Response within 12 hours after-sales service.

Design Diagram
Overhead power line transmission conductor stringing block china
Overhead power line transmission conductor stringing block china
